MACHINE SPECIFICATIONS

• Gage: .017" Min to .250" Max
• Coil Width: 24" Min to 72" Max
• Coil I.D.: 20" Min to 24" Max
• Coil O.D.: 30" Min to 72" Max
• Coil Weight Capacity: up to 50,000Lbs
• Production Speeds: up to 1,000 FPM

SLITTER HEAD

• Two Slitter Heads with Quick Change Feature
• This special feature allows us to maximize production by eliminating down time for set-ups

STRAND EXTENSIONER

• Improves strip shape
• Maintains critical material surface quality
• Reduces camber, crossbow and deburrs slit product
• Eliminates the unsafe practice of paper stuffing during slitting

RECOILER

• Coil Weight Capacity up to 50,000Lbs
• O.D. up to 72” Max

FINISHED PRODUCT TURNSTILE

• 4 Arm turnstile allows for continuous production
• Coil Weight Capacity per arm to 50,000Lbs
